10kWh Portable Outdoor Home Power Station
Request a Quote
Enter the quantity you need and add to your quote list for pricing inquiries.
Description
| Category | Item | Specification |
|---|---|---|
| Basic Info | Model | 087-INV62-10KW |
| Battery Parameters | Battery Type | Lithium Iron Phosphate (LFP), 3.2V/206Ah |
| Battery Voltage Range | 40V~60V DC | |
| Max. Charge Current | 200A | |
| Max. Discharge Current | 200A | |
| Rated Charging Power | 6200W | |
| Rated Discharging Power | 6200W | |
| Total Battery Energy | 10547Wh | |
| Series-Parallel Connection | 1P16S | |
| Cycle Life | 6000 cycles @ 0.5C, 90% DOD (25℃) | |
| PV Input | Max. PV Input Power | 6000W |
| PV Startup Voltage | 120V DC | |
| MPPT Operating Voltage Range | 120V~450V DC | |
| Max. PV Input Voltage | 500V DC | |
| Single MPPT Input Current | 20A | |
| Max. Single MPPT Input Current | 22A | |
| Number of MPPT Channels | 1 | |
| On-Grid AC Output | Rated On-Grid Output Power | 6200W |
| Max. On-Grid Output Power | 6200W | |
| Rated Output Voltage | 220V/230V AC | |
| Output Voltage Range | 170V~230V AC | |
| Rated Frequency | 50/60Hz ±2% | |
| Max. On-Grid Output Current | 24A | |
| Off-Grid Switching Time | 10ms | |
| Power Factor | 0.8 Leading ~ 0.8 Lagging | |
| THD | ＜3% | |
| Off-Grid AC Output | Rated Off-Grid Output Power | 6200W |
| Max. Off-Grid Output Power | 6200W | |
| Rated Output Voltage | 220V/230V AC | |
| Output Voltage Range | 170V~230V AC | |
| Rated Frequency | 50/60Hz ±2% | |
| Max. Off-Grid Output Current | 24A | |
| THD | ＜3% | |
| Efficiency | Max. Conversion Efficiency | ＞88% |
| Output Ports | 2 × USB-A | Max. 18W (QC: 5V/2.4A, 9V/2A, 12V/1.5A) |
| 2 × Type-C | Max. 100W (PD: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A) | |
| 2 × 5521 DC Socket | Total Max. 120W (12V/10A) | |
| 3 × AC Socket | Single port max. 2000W | |
| Terminal Block | Max. 6200W | |
| Input Ports | PV XT90 Port | Max. 22A |
| AC Inlet | Max. 10A | |
| Terminal Block | Max. 6200W | |
| Parallel Function | Max. Parallel Units | 16 units (including main unit) |
| Max. Single-Phase Parallel Units | 6 units | |
| Max. Three-Phase Parallel Units | 6 units | |
| General Parameters | Operating Temperature | -15℃ ~ 55℃ |
| Relative Humidity | 5% ~ 95% | |
| Ingress Protection | IP41 | |
| Noise Level | ≤60dB | |
| Communication | RS485 / WiFi / Bluetooth / CAN / GPRS / Dry Contact | |
| Cooling Mode | Fan Cooling | |
| Remote Monitor & Upgrade | Supported via Mobile APP | |
| Compliance Standard | IEC/EN62109-1, IEC/EN62109-2, IEC/EN61000 Series, VDE4105 | |
| Optional Functions | Parallel operation, Capacity expansion, WiFi, Anti-islanding CT | |
| Dimension & Weight | Product Dimension (L×W×H) | 550×280×987 mm |
| Package Dimension (L×W×H) | 1140×685×495 mm | |
| Net Weight | 115kg | |
| Gross Weight | 148kg |
